Trunnion Mounted Fully-Welded Body Ball Valves are typically used for gas transmission pipeline projects, buried pipelines (underground).

Size: 2” up to 56“ (DN 50 up to DN 1400)

Pressure Rating: ASME 150# to 2500#

Materials: Generally Carbon Steels with either Stainless Steel or ENP Coated Carbon Steel internals.

Design Standard: API 6D, API 608, MESC SPE 77 / 130 API6DSS, MESC SPE 77/210

Pressure / Temperature Rating: ASME B 16.34 Test (Inspection) Standard : API6DSS, API 598, API 6D, ISO 5208, MESC SPE 77/132, 77 / 300, 77/312, 77/200, 77/210, API 6FA, ISO 10497, API607, ISO 15848-1&2, BS 6364

Operation: Gear, Actuator (Gas-Hydraulic, Pneumatic, Hydraulic, Electro-Hydraulic and Electric Motorised)

Special Design Feature also available:
• Line Break System
• Stem Extension
• Single & Double Piston Seat Design
• Primary Metal and Secondary Soft Seat Design
• Emergency Seat and Stem Lubricant Injection

Photos
