Globe Valves-Hawa Valves manufacturers in india

Globe Valves are extensively used through-out the hydrocarbon, energy and process & the power industries.

Size: ½” up to 24“ (DN 15 up to DN 600)

Pressure Rating: ASME 150# to 2500#

Materials: Carbon Steels, Low Temperature Carbon Steel, Martensitic Steels, Austenitic Stainless Steel, Duplex Stainless Steels, Super Duplex Stainless Steels, Nickel Alloys, Nickel Aluminum Bronze, Hastelloy, Inconel, Titanium Alloy & Carbon Steel with Internal Corrosion Resistant Alloy (CRA) Overlay

Design Standard: API 602, MESC SPE 77 / 103, BS 1873 DIN 3356

Pressure / Temperature Rating: ASME B 16.34

Test (Inspection) Standard: API 598, API 6D, MESC 77/103, ISO 5208, ISO15848 -1&2, BS 6364

Construction Details: Bolted Bonnet / Pressure Seal Bonnet, OS & Y Type Rising Stem

End Connection: Screwed, Socket Weld, Flanged, Hub End, Butt-Weld

Operator / Actuator: Lever, Gear, Actuator (Pneumatic, Hydraulic, Electro-Hydraulic and Electric Motorised)

Globe Valves are available in three different types:
• Bolted Bonnet
• Pressure seal
• Bellows Seal

Cryogenic Service
Globe Valves can be designed in a special version suitable for cryogenic service. In this case, all the materials and technical features are designed to withstand minimum design temperature required by the Customer, down to Cryogenic -196°C. If required by the customer, specific Cryogenic Tests are performed to verify the behaviour of production valves in terms of valve torque, sealing capability, emissions vs the ambient.

Photos
